OTR Grader tire
* Suitable for Grader , Loader, Axcavator and Bulldozer
* work on soft muddy ground
* Good self-cleaning
* Wide tread
* Excellent driving performance in muddy road
| Size | PR | Standard Rim (mm) | Tread Depth (mm) | Overall Dia (mm) | Section Width (mm) | Max Loading (kg) |
| 12.5/70-16 | 6 | 10.00 | 16.5 | 848 | 316 | 1410 |
| 15.5/60-18 | 8 | 13.00 | 18 | 937 | 404 | 2195 |
| 15.5-25 | 12 | 12.00/1.3 | 23.5 | 1275 | 395 | 5600 |
| 17.5-25 | 12/16 | 14.00/1.5 | 26 | 1330 | 410 | 6150 |
| 20.5-25 | 16 | 17.00/2.0 | 29.5 | 1490 | 520 | 8250 |
| 23.5-25 | 16 | 19.50/2.5 | 31.5 | 1615 | 595 | 9500 |
| 13.00-24 | 12/16 | 9.00 | 23.5 | 1300 | 350 | 3200 |
| 14.00-24 | 16 | 9.00 | 25 | 1370 | 375 | 3650/3075 |
| 15.5-25 | 16 | 12.00/1.3 | 23.5 | 1275 | 395 | 3750 |
| 17.5-25 | 20 | 14.00/1.5 | 26 | 1330 | 410 | 5000 |
